Ortofon SPU Classic N E Phono Cartridge
You can earn loyalty points on every order you place on this website. If you select to create an account at checkout, your loyalty points will be saved and you can use these to discount future orders online.
Each product page shows you how many loyalty points you can earn when you order that item. Essentially, for each £1 you spend, you earn 1 loyalty point and for every 1 point earned, 1p will be added to your loyalty point balance (this is the same as some of the UK's biggest loyalty point cards). So for example, if you spend £500, you'll earn 500 loyalty points which can be used to discount a future order by £5.00.
Available - Usually ships within 2-3 days
Features
| Warranty The length of time your product is protected by warranty | 2 Years |
|---|---|
| Manufacturer | Ortofon |
Tech Specs
Out Voltage @1kHz, 5cm/sec: 200 µV
Channel Balance @1kHz: < 1 dB
Channel Separation @1kHz: > 20 dB
Channel Separation @15kHz: > 10 dB
Freq Range (@-3dB): 20-25.000Hz
Freq Response (±3dB): 20 - 20.000Hz
Recommended Tracking @315Hz: 65 µm
Compliance, Dynamic, Lateral: 8µm/mN
Stylus Type: Nude Elliptical
Stylus Tip Radius: R 18 µm
Tracking Force: 3-5g (30-50 mN)
Recommended Tracking: 4.0g (40 mN)
Tracking Angle: 20°
Internal Impedance/DC Resistance: 6 Ohm
Recommended Load Impedance: > 10 Ohm
Coilwire: High Purity Copper (OFC)
Cartridge Colour: Black
Cartridge Weight: 13 g
Description
Ortofon's SPU Classic N E provides the same sound reproduction properties as the SPU Classic GM E series, but is sold without the integrated headshell unit. The SPU Classic N E is a Moving Coil cartridge with an elliptical stylus profile and provides more detailed sound reproduction and expansive imaging.
Listeners can mount the SPU Classic N E on a traditional headshell while those with vintage SPU-type headshells can use the Classic N to recreate an authentic and functional SPU cartridge.
